PET & RPET Sheet Extrusion Line
| Place of Origin: | China |
| Brand Name: | JWELL |
| Certification: | CE ISO TUV UL, QS, GMP |
| Minimum Order Quantity: | ≥1 |
| Price: | To be negotiated |
| Delivery Time: | 90 days |
| Payment Terms: | T/T, L/C |
| Warranty: | One year |
| International Commercial Terms: | FOB, CIF, CFR, EXW |
Product Description
JWELL PET/rPET Sheet Production Line – For Superior Clarity & Efficiency
When producing high-transparency sheets with optimal visual quality, the JWELL PET/rPET Production Line delivers unmatched performance. Our high-efficiency single-screw extrusion systems ensure:
● Low energy consumption per unit
● Exceptional sheet performance with outstanding transparency
● Precision thickness control via automatic T-die and online thickness gauges
Ideal for high-end packaging and demanding applications, this line helps reduce costs, boost productivity, and strengthen competitiveness through automation and consistency.
Applications
√ Food Packaging
Transparent containers & trays (for fruits, salads, pastries, etc.)
Preforms for beverage bottles (mineral water, juice bottles, etc.)
√ Pharmaceutical Packaging
Blister packs for medicines, sterile medical trays
√ Electronics Packaging
Anti-static trays (for chips, precision components)
Cosmetic/luxury product display cases
√ Industrial & Printing
Label films, advertising lightbox panels
Eco-Friendly Applications (rPET)
Recycled packaging materials, fiber-filled products
Features: High transparency, heat resistance, recyclability—ideal for demanding applications.
Specifications
| Main technical parameter | ||||
| Model | Single layer | Single layer | Single layer | Multi layer |
| Extruder specification | JWS120-1000 | JWS130-1000 | JWS150-1500 | JWS160/90-1500 |
| Thickness of the product | 0.15-2mm | 0.15-2mm | 0.15-2mm | 0.2-2mm |
| Main motor power | 132kw | 160kw | 250kw | 315/75kw |
| Max extrusion capacity | 500kg/h | 600kg/h | 800kg/h | 1200kg/h |
| The latest model can reach 1500kg/h per hour | ||||
Competitive Advantage
● Efficient Devolatilization and Venting: Solves the core problems of PET hygroscopicity and hydrolytic degradation.
● Powerful Mixing and Dispersion: Ensures uniform distribution of additives and fillers, and homogenization of recycled material.
● Precise Process Control: Reduces thermal degradation, ensuring melt quality and stability.
● High Flexibility and Adaptability: Capable of handling various forms of PET raw materials (especially recycled materials) and complex formulations.
● High Output and High Quality: Enables large-scale, stable production, yielding high-performance PET pellets or directly molded products.
Although the initial investment for twin-screw extruders is typically higher than for single-screw extruders, when processing PET—especially for applications demanding high quality (such as bottle-grade, film-grade, fiber-grade) or when using large amounts of recycled material—their advantages in quality, efficiency, stability, and material adaptability make them the more ideal choice. From the perspective of overall production costs and product quality, they often prove more economically advantageous.
Certification
FAQs
Q: Can we visit your factory?
Sure. We located in No.118 Shangshang road Channgzhou Liyang city Jiangsu Province China, you can fly to ShanghaiPudong International Airport or Nanjing Lukou airport. We can pick you up in the Airport.
Q: How can we get the exact price of plastic extrusion machine?
Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with quotation.
Q: Do you provide any spare parts with machine?
Yes, we offer all necessary spare parts before shipment.
Q: How about JWELL after-sale service?
The customer can send the engineer to our JWELL with training.
JWELL supplies the complete technical support documents and the relative drawings of the electric components written in Chinese and English.
JWELL send enough technicians to the customer’s company for installation and testing the lines.
Q: What is the lead time?
The machine is customized , it takes about60-90 days after deposit, It needs to be determined based on the actual technical configuration.
Q: What is the warranty period for JWELL machine?
The guarantee period is one years and service is available lifelong.
Q: Do you provide custom machines?
Most of our machines are customized. our goal is efficiency and stable performance. We design the machines according to customers products to meet customer' needs.
Q: How can we install the machine when it arrives?
We send experienced technicians to customer's country for guiding the installation and commission the machine,also train the customer's employees.
Q: What's the advantage of JWELL?
We provide customers with turnkey projects. Including plant design plastic machine and mold installation, debugging,also we can source the auxiliary equipments for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.
